9Z5AJ
Rocker Mechanism
| User weight range | 45-105 kg |
|
Outside size |
106X74 mm |
|
Backrest recline angle |
12° |
|
Recline movement |
-6°~12° |
|
Start Angle |
0° |
| Lock Mode of actuation | Lever control |
| Tension Mode of actuation |
- |
1. Tile function with front -6° and back 12°
2. It offers left and right swing
3. 360-degree swivel
4. Lock at initial position.
5. Hole dimension: 120X120~140X140mm
